Waterproof Dual-Foot Floor Mat

Product Introduction
Shandong Muke Sensor's core products cover a full range of industrial safety sensing equipment, including safety light curtains, bending machine laser protection devices, and safety carpets. They are widely used in automotive manufacturing, white goods, textiles, packaging, new energy, stamping and forging, and non-standard automation fields, providing customized safety sensing solutions for customers worldwide.

Product DetailsOnline Message


Industry Advantages of the Product

1. Made from special load-bearing rubber (EPM/EPDM), offering high tensile strength, excellent tear resistance, and superior abrasion resistance.

2. Capable of operating over millions of cycles.

3. Exhibits outstanding resistance to corrosion from a wide range of chemicals, including acids, alkalis, and salts.

4. Generates a switching signal upon detecting sufficient pressure, thereby enabling safety protection for a defined area.

5. Typical applications include: automatic sliding doors, welding robots, rubber and plastic machinery, assembly equipment, material handling systems, packaging machines, and stamping presses.

6. When used in conjunction with a dedicated controller, it can monitor the operational status of the safety mat, forming a more robust and reliable safety protection system


Detailed Product Specifications

◉ Dimensions: Customizable up to 2000 × 1500 mm

◉ Load Capacity: Dynamic load: 500 kg; Static load: 800 kg

◉ Surface Material: Rubber (black)

◉ Operating Temperature: –10 °C to 60 °C (no freezing, no condensation)

◉ Mat Thickness: 12 mm ◉ Chemical Resistance: Excellent

◉ Activation Force: 30 kg (equivalent to an adult’s step)

◉ Weight: 28 kg ◉ Response Time: ≤ 30 ms

◉ Service Life: Rated for over millions of actuation cycles

◉ Antistatic Rating: Class III antistatic, surface resistance ≈ 10¹¹ Ω

◉ Flame Retardancy Rating: UL 94 V-0

Our advantages

We are Shandong Moncee, a modern integrated manufacturing enterprise specializing in R&D, design, production, sales, and service, with our own production facility spanning 20,000 m².

The MILS-F31C LiDAR delivers tailored, cost-effective solutions for a wide range of requirements—whether providing compact data for environmental monitoring and object detection, offering greater flexibility in industrial settings and building automation, or enabling mobile platforms such as Autonomous Mobile Robots (AMRs), service robots, and ground transportation vehicles.




Long service life

Made from special load-bearing rubber material with high tensile strength, excellent tear resistance, and abrasion resistance—capable of enduring over one million operational cycles.

Excellent corrosion resistance

Offers superior resistance to a wide range of chemicals, including acids, alkalis, and salts, enabling reliable performance in diverse working environments.

Wide range of applications

Typical application scenarios include: automatic sensor doors, welding robots, rubber and plastic machinery, assembly equipment, material handling systems, packaging machinery, stamping machines, and more.

Order and Ship Immediately (Packing List)
